C4 Fabrication Tacoma Overland Series Front Bumper / 2nd Gen / 2005-2011

The C4 Fabrication Tacoma Overland Series Front Bumper for the 2nd Gen Toyota Tacoma (2005–2011) is a bolt-on front-end upgrade built for serious off-road and overland use. It delivers rugged protection, enhanced tire clearance, and the adaptability needed for larger tires and diverse driving conditions.

Key Benefits

• 100% bolt-on design with no welding required for a straightforward install.
• Significantly improved tire clearance and a better approach angle to tackle rough terrain.
• Supports larger tire setups without compromising protection or clearance.
• 3/16" laser-cut P&O steel shell with 1/4" mounting plates for durable, rigid mounting.
• 3/4" thick D-Ring tabs, standard on every bumper and fully welded front and back for dependable recovery points.
• Bull bar tubing:.120" wall, 1 3/4" diameter HREW for sturdy bumper protection.
• Designed to fit 30" single-row light bars; specifically optimized for Baja Designs S8 and compatible with Extreme LED 30" 5D and RIGID 30" SR series.

Winch Compatibility & Wiring

• Fits most winches in the 8k–12k range.
• Winches with the ability to relocate the electrical control box are recommended.
• Integrated control box winches may require some trimming of grille support brackets to fit.
• Common compatible models include ComeUp, Smittybilt X20, Warn Zeon, and VR series.
• For best fit and function, use synthetic rope with a hawse-style fairlead; some roller fairleads may be too large for the bumper’s recessed fairlead mounting plate.

Lighting, Fog & Accessories

• Fog light pockets designed for Baja Designs Squadron lights; factory fog lights are not supported.
• Bumper is designed to accommodate a 30" light bar (single-row) with specific design work for Baja Designs S8.

Materials, Finish & Maintenance

• Constructed from 3/16" laser-cut P&O steel with 1/4" thick mounting plates for rigidity.
• Finish options include powder coating; if you don’t choose the powder-coated option, painting or powder coating is recommended before installation to prevent rust.
• Weight ranges from 125 lbs (without bull bar) up to 145 lbs (with full-height bull bar and headlight hoops), depending on configuration.

Additional Brackets & Value

Additional Front Bumper Frame Support Brackets are included with all 2nd Gen Tacoma Overland and Hybrid front bumpers — a value of $177.00.

Fitment Scope & Notes

• Specifically designed for 2005–2011 2nd Gen Toyota Tacomas.
• Requires painting or powder coating if the powder-coated option isn’t selected to prevent rust.
• 30" light-bar compatibility includes Baja Designs S8, Extreme LED 30" 5D, and RIGID 30" SR series.
