• ORACLE Lighting TITAN 4 90W High Performance Auxiliary Flood Light - IR LED by Oracle Lighting

Oracle Lighting

ORACLE Lighting TITAN 4 90W High Performance Auxiliary Flood Light - IR LED

ORACLE Lighting TITAN 4 90W High Performance Auxiliary Flood Light - IR LED

Read Product Details

5933-F-IR

Out of Stock
$364.60
  • Secure checkout
    SSL encrypted payment
  • Fast Shipping
    2-3 Business days

DOES THIS FIT MY VEHICLE?
Sold out

Description

ORACLE Lighting TITAN 4 90W IR LED High-Performance Auxiliary Flood Light

  • 90W infrared (IR) LED option designed for night-vision operations on rugged off-road rigs.
  • Wide input voltage range of 10V–32V DC with full over/under voltage protection and reverse polarity protection for reliable power anywhere your vehicle goes.
  • Heavy-Duty Industrial Bracket Design reinforced with an integrated Anti-Vibration Shock Plate, proven to withstand high-impact environments and 60G shock testing.
  • Certified for real-world use with CE, RoHS, R10, and R112 compliance for safety and environmental standards.
  • Long service life and durability features, engineered for 50,000+ hours of operation.
  • Multiple LED options available: White LED for brightness, Yellow LED for fog-cutting clarity, and Infrared LED (IR) for night-vision operations.
  • Backed by a 2-year warranty for added peace of mind on demanding off-road journeys.

Features

  • Flood/IR
  • Heavy Duty Industrial Bracket Design
  • EMC Test: CISPR 25 2008
  • GRADE: R10 Class 4
  • Ingress Protection IEC60529
  • GRADE: IP69K
  • Input Voltage: 10V-32V
  • Power Draw: 5A@12V / 2.5A@24V
  • LED Chip: OSRAM
  • Operating Power: 90W
  • CCT Color Temp: 6000K
  • Operating Temp: -40°F to 185°F
  • RAW Lumens 6000K: 10
  • 500 lm
  • RAW Lumens 3400K: 9700 lm
  • Optional Anti-Vibration Shock Plate
  • Projection Distance: 640m
  • Lux - Spot: (640 Meters) 0.25 lx
  • Lux - Flood: (240 Meters) 0.25 lx
  • Connector Type: Deutsch DT 2-Pin
  • Lens Material: Polycarbonate
  • Housing Material: Powdercoated Aluminum
  • Mounting Hardware: 304 Stainless Steel
  • Ingress Protection: IP69K Waterproof
  • Lamp Dimensions: 120mm x 110mm x 86mm
  • Lamp Weight: 5 lbs
  • Wide Voltage Input Range 10V-32VDC
  • In the Box: (1) 90W High Performance Auxiliary Light (1) Deutsch Connector Pigtail
  • CE
  • RoHS
  • R10 and R112 Certifications
  • 50
  • 000 Hours Runtime
  • 2 Year Warranty
  • Vibration: IEC 60068-2-6
  • 15.6Grms24—2000Hz
  • Shock Test: IEC 60068-2-27
  • GRADE: 2008 60G

Specifications

Dimensions

8 Inches
Length
8 Inches
Width
4 Inches
Height
5 lbs
Weight
